WATER COOLED  BRAKES

Only CoolForce brakes offer a removable composite water jacket insert to reduce lifecycle costs by simplifying field maintenance and rebuilds.

CoolForce brakes have the same torque rating and thermal performance of traditional water-cooled brakes, but their innovative composite jacket design eliminates time-consuming weld repair and re-machining of the interior features of the water jacket. Simply remove the worn insert, and replace it. The replaceable insert also eliminates corrosion resulting from contact of the copper backing plate with the cast iron supporting structure inside the water jacket.

In most circumstances, we can retrofit your existing water-cooled brakes with our composite water jacket inserts. That means all of your water-cooled brakes can deliver simpler, faster and lower-cost water jacket rebuilds going forward.


I'd like to request a quote.

FEATURES AND BENEFITS

AIR-ACTUATED BRAKES			AIR RELEASE SPRING SET BRAKES
MODEL NUMBER	TORQUE RATING LB-IN		MODEL NUMBER	TORQUE RATING LB-IN
CF118AS	48,800		CF118SS	40,000
CF218AS	97,800		CF218SS	76,000
CF318AS	146,400		CF318SS	112,000
CF418AS	195,200		CF418SS	148,000
CF124AS	100,000		CF124SS	82,000
CF224AS	200,000		CF224SS	157,000
CF324AS	300,000		CF324SS	232,000
CF424AS	400,000		CF424SS	328,000
CF136AS	295,000		CF136SS	283,000
CF236AS	590,000		CF236SS	532,000
CF336AS	885,000		CF336SS	781,000
CF436AS	1,180,000		CF436SS	1,030,000
